HighTemp DL400

(1 customer review)

From: £375.00 excl vat

FREE UK shipping on orders over £50

HighTemp DL400 is the first Photocentric temperature resistant resin possessing superior properties of both strength and stiffness. It can handle impact, compression, fatigue, high temperatures and moisture without bending or deforming. Photocentric’s HighTemp DL400 can be used for quick printing applications with an impressive layer thickness of 350 μm.

Photocentric Resin Cleaner 5L

Designed to clean excess photopolymer resin off 3D printed parts.

25 Resin Filters

Use to filter resin when pouring back into container of origin after use.

1 in stock (can be backordered)

5Kg

SKU: DAYHTMAM05 Categories: , Tag:

Best Used for:

• Hot fluid and gas manifolds
• Moulds and inserts
• Heat resistant housings and fixtures
• Outdoor applications

USPs:

• Temperature resistant (Heat Deflection Temperature of 230 °C)
• Excellent long-lasting performance under heat and stress
• Quick and fast prototyping 350 μm layer
• Simulating the strength and stiffness of glass filled Nylon 6
• Smooth surface finish and ability to print fine details
• Minimal shrinkage

Compatible Printers:

LC Magna

Properties
Tensile Properties
Tensile Modulus *
Ultimate Tensile Strength *
Elongation at break *
3800-4000 MPa
80 MPa
4%
ASTM D638
ASTM D638
ASTM D638
Flexural Properties
Flexural Strength *
Flexural Modulus *
109 MPa
3300 MPa
ASTM D790
ASTM D790
Impact Properties
Impact Strength Notched Izod *
3.1 kJ/m2
ISO 180
General Properties
Hardness *
Heat Deflection Temperature *
Viscosity
Density
Storage
Colour
95 Shore D
230 °C
650 cPs
1.10 g/cm3
10<T>50°C
Amber
ASTM D2240
ASTM D648 (0.455 MPa)
At 25°C Brookfield spindle 3
* Post cured for 1hr at 60°C in Cure L2
Properties
Tensile Properties
Tensile Modulus *
3800-4000 MPa
ASTM D638



Ultimate Tensile Strength *
80 MPa
ASTM D638



Elongation at break *
4%
ASTM D638
Flexural Properties
Flexural Strength *
109 MPa
ASTM D790



Flexural Modulus *
3300 MPa
ASTM D790
Impact Properties
Impact Strength Notched Izod *
3.1 kJ/m2
ISO 180
General Properties
Hardness *
95 Shore D
ASTM D2240



Heat Deflection Temperature *
230 °C
ASTM D648 (0.455 MPa)



Viscosity
650 cPs
At 25°C Brookfield spindle 3



Density
1.10 g/cm3



Storage
10<T>50°C



Colour
Amber



* Post cured for 1hr at 60°C in Cure L2



1 review for HighTemp DL400

  1. Jeff Barlow, Dustless Technologies

    This is a great product. I think it was a new release when we tried it. We needed a resin that would give a smooth finish and would easily handle high temperatures which it did – the fact that it can handle fine detail as well is a definite plus.
