World leaders in large format LCD 3D printing
High performance, affordable, industrial 3D Printers. Move from prototyping to mass manufacture with LCD. Delivering resolution, functionality, speed and value.
We approach 3D printing as a photopolymer manufacturer first. Most 3D printing companies don’t make resin.
We are vertically integrated as a manufacturer of materials, machines and parts and we believe this is essential to enable digital mass manufacturing.
LCD & Daylight Technology
Photocentric invented LCD 3D printing, the largest technological advance in 3D printing in the last 5 years. Small format LCD printers have delivered new standards in resolution, print speed, and affordability. An even greater transformation is now happening with LCD in industrial format.
With no screen degradation from UV, Daylight cures more evenly across the entire platform from controlled depth of cure creating dimensionally accurate, functional parts.
LCD & Daylight Technology
Photocentric invented LCD 3D printing, the largest technological advance in 3D printing in the last 5 years. Small format LCD printers have delivered new standards in resolution, print speed, and affordability. An even greater transformation is now happening with LCD in industrial format.
With no screen degradation from UV, Daylight cures more evenly across the entire platform from controlled depth of cure creating dimensionally accurate, functional parts.
Liquid Crystal Titan
The largest LCD 3D printer in the world
Liquid Crystal Titan, 8K 32” screen 3D printer, rapidly and reliably prints very large parts at high resolution. Nothing creates more parts, more cost-effectively.
Titan is part of a complete manufacturing solution supplied with post processing units, Daylight resins, design software, recycling options, training, and part design consultancy.
Liquid Crystal Titan
The largest LCD 3D printer in the world
Liquid Crystal Titan, 8K 32” screen 3D printer, rapidly and reliably prints very large parts at high resolution. Nothing creates more parts, more cost-effectively. Titan is part of a complete manufacturing solution supplied with post processing units, Daylight resins, design software, recycling options, training, and part design consultancy.
Build volume
695 x 385 x 1200 mm
27.3 x 15.2 x 47.2″
Print speed
≤ 86mm per hour
≤ 3.4” per hour
Pixel pitch
91μm
3.6 thou
Liquid Crystal Magna
Large format industrial LCD 3D printer
Liquid Crystal Magna 3D printer is the proven workhorse of digital manufacturing delivering surprising resolution across a large area, printing rapidly, reliably and cost-effectively, making it unique among large format printers. Magna is part of a complete manufacturing solution supplied with post processing units, Daylight resins, design software, recycling options, training, and part design consultancy.
Build volume
510 x 280 x 350 mm
20.1 x 11 x 13.8”
Print speed
≤ 86mm per hour
≤ 3.4” per hour
Pixel pitch
137μm
5.4 thou
Liquid Crystal Opus
High resolution open material platform LCD 3D printer
Liquid Crystal Opus is a desktop 3D printer delivering both capacity & resolution. Built for reliability with no screen degradation although printing with UV light.
Opus is part of a complete manufacturing solution supplied with post processing units, UV resins, design software, recycling options, training, and part design consultancy
Build volume
310 x 174 x 220 mm
12.2 x 6.9 x 8.7″
Print speed
18mm per hour
0.71″ per hour
Pixel pitch
81μm
3.2 thou
Liquid Crystal Magna
Large format industrial LCD 3D printer
Liquid Crystal Magna 3D printer is the proven workhorse of digital manufacturing delivering surprising resolution across a large area, printing rapidly, reliably and cost-effectively, making it unique among large format printers.
Magna is part of a complete manufacturing solution supplied with post processing units, Daylight resins, design software, recycling options, training, and part design consultancy.
Liquid Crystal Opus
High resolution open material
platform LCD 3D printer
Liquid Crystal Opus is a desktop 3D printer delivering both capacity & resolution. Built for reliability with no screen degradation although printing with UV light.
Opus is part of a complete manufacturing solution supplied with post processing units, UV resins, design software, recycling options, training, and part design consultancy
Compare 3D printers
Choose the right 3D printer for you
UV Technology
Light output wavelength 405nm
Daylight Technology
Light output wavelength 460nm
Daylight Technology
Light output wavelength 460nm
Build volume
310 x 174 x 220mm
12.2(w) x 6.9(d) x 8.7(h)″
Build volume
510 x 280 x 350mm
20.1(w) x 11(d) x 13.8(h)”
Build volume
695 x 385 x 1200mm
27.3(w) x 15.2(d) x 47.2(h)″
Print speed
18mm per hour at 100µm
0.71″ per hour
Print speed
≤ 86mm per hour at 350µm
≤ 3.4” per hour
Print speed
≤ 86mm per hr at 350µm
≤ 3.4″ per hr
Layer thickness
25 to 100µm
Layer thickness
25 to 350µm
Layer thickness
50 to 350µm
Pixel pitch
81μm
3.2 thou
Pixel pitch
137μm
5.4 thou
Pixel pitch
91μm
3.6 thou
LCD screen
14″ 4K 3840 x 2160px
LCD screen
23.8″ 4K 3840 x 2160 px
LCD screen
32″ 8K 7680 x 4320 px
Materials
UV resins, open system
Materials
Daylight, BASF Ultracur3D®
Materials
Daylight, BASF Ultracur3D®
Resin autofill system
Connectivity
Wi-Fi, Ethernet, USB 3.0
Connectivity
Wi-Fi, Ethernet, USB 3.0
Connectivity
Wi-Fi, Ethernet, USB 3.0
Software
Photocentric Studio*
Software
Photocentric Studio & Voxel Dance**
Software
Photocentric Studio & Voxel Dance*
7″ touchscreen
Integrated control system
7″ touchscreen
Integrated control system
13″ touchscreen
Integrated control system
Power input
110-240 VAC
Power input
110-240 VAC
Power input
32A 230v Single Phase
Printer dimensions
415(w) x 475(d) x 605(h) mm
16.4(w) x 18.7(d) x 23.8(h)”
Printer dimensions
852(w) x 641(d) x 900(h) mm
33.5(w) x 25.2(d) x 35.4(h)”
Printer dimensions
1544(w) x 926(d) x 2137(h) mm
60.8(w) x 36.5(d) x84.1(h)”
* Free perpetual licence included with printer
** Free perpetual Studio licence included with printer. Voxel Dance purchased separatley
